Measuring
Flow Meters
Flow meters for Air / Water
4L
Illustration exemplary
4L100G140318PVFP
Flow meter (Series 4L) for air or water, with rear female G- or NPT-thread and valve
Technical information
All data in mm; Illustration exemplary
Technical data
Connection | G1/8" |
Flow Rate | 4-40l/h |
Medium | Air |
Material Body | PVDF |
Material O-ring | FKM |
Material Measuring Tube | DURAN® glass |
Material Spindle | PCTFE |
Material Float for Air | glass |
Material Float for Water | stainless steel |
Material Protective Pipe | PMMA |
Pressure Stage | PN 3 |
