Flow meter (Series 4L) for air or water, with rear female G- or NPT-thread and valve

Illustration exemplary

4L100G150318PVFK

Flow meter (Series 4L) for air or water, with rear female G- or NPT-thread and valve

Save datasheet PDF Bookmark

Technical information

All data in mm; Illustration exemplary

Technical data

Connection	G1/8"
Flow Rate	10-100l/h
Medium	Air
Material Body	PVDF
Material O-ring	FFKM
Material Measuring Tube	DURAN® glass
Material Spindle	PCTFE
Material Float for Air	glass
Material Float for Water	stainless steel
Material Protective Pipe	PMMA
Pressure Stage	PN 3
