Ball Valve with Electrical Actuator 6R and 6RD
6R750F
Illustration exemplary
6R850F0414PVFP
Ball valve (Series 6R) with electrical part-turn actuator (COMPACT), with female G- or NPT-thread, 5-way, with L-bore
Technical information
All data in mm; Illustration exemplary
Technical data
Nominal Diameter | DN04 |
Connection | NPT1/4" |
Material Body | PVDF |
Material O-ring | FKM |
Material Ball | PVDF |
Material Sealing Sleeve | PTFE |
Material Pressure Screw | PVDF |
Kvs Value | 0.58 m³/h |
Max. Media Temperature | 140°C |
Pressure Stage | PN10 |
Electrical Actuator Max. Ambient Temperature | 70°C |
Electrical Actuator Voltage | 24 VDC |
Electrical Actuator Power Consumption | 180 mA |
Electrical Actuator Torque | 1.2 Nm |
Electrical Actuator Protection Class to EN 60529 | IP 65 |
Electrical Actuator Connection | 8-pole round plug with 2 m connection cable |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
