Manual Ball Valve 6L and 6A
6L733F
Illustration exemplary
6L833F0414PPEP
Ball valve (Series 6L) with female G- or NPT-thread, 3-way, horizontal, with T-bore
Technical information
All data in mm; Illustration exemplary
Technical data
Connection | NPT1/4" |
Nominal Diameter | DN04 |
Material Body | PP |
Material O-ring | EPDM |
Material Ball | PP |
Material Sealing Sleeve | PTFE |
Material Pressure Screw | PP |
Kvs Value | 0.58 m³/h |
Max. Media Temperature | 90°C |
Pressure Stage | PN10 |
Starting from the nominal pressure rating (at 20°C), the permissible pressure reduces with increasing media temperature.
